Model Name:CB1100
Manufacturer:HONDA
Model Year:2010
This model was based on the latest liter-class naked model, CB1100 Type 1, which mounted the traditional air-cooled 4-cylinder engine. It also had a stable braking ability and an ABS system that secured ones safety. It featured a combined ABS system that incorporated interlocking front & rear brake function. With this system, the rear brake input was automatically and ideally distributed to the front brake. Because of this, the front brake caliper had been switched from the standard opposed 4POT model to the pin-slide 3POT model. It had become heavier by 4kg. No major changes were made to the engine or the vehicle standard composition.
Specifications:
[Basic spec]
| Manufacturer | HONDA | Engine Type | Air-Cooled 4 Stroke Straight 4 Cylinder DOHC 4-Valve |
|---|---|---|---|
| Model Name | CB1100 | Starter | Self Starter |
| Grade | ABS Type I | Maximum Output (ps) | 88ps(65kw)/7500rpm |
| Drive Train | - | Maximum Torque (kgf/m) | 9.4kg-m(92N-m)/5000rpm |
| Model Type | SC65 | Curb Weight | 247 |
| Displacement | 1140 | Dry Weight | 226(Approximate Value) |
| Sales Launch Year | 2010/3 | Fuel Efficiency by Catalog | 27.0 km/L (at 60 km/h) |
| Height/Width/Length | 1130/-/2205 | Fuel Tank Capacity | 14 |
| Seat Height | 765 | Distance to Empty | - |
| Front Tire Indication | 110/80R18 58V | Fuel Supply | Injection |
| Rear Tire Indication | 140/70R18 70V |
[Service data]
| Standard Plug | LMAR8A-9S | Chain Size | 530 |
|---|---|---|---|
| Number of Used Plugs | 4 | Chain Link Number | 110 |
| Engine Oil Amount | 4.9 | Battery Code | YTZ14S |
| Engine Oil (Refill) | 3.8L | Headlight | 12V 60w/55w |
| Engine Oil (Element Replacement) | 3.9L | Headlight Type | H4 |
| Front Blinker Rating | - | Headlight Remarks | - |
| Drive Sprocket Teeth Number | 18 | Tail Light Rating | - |
| Driven Sprocket Teeth Number | 39 | Rear Blinker Rating | - |
[Machine detail]
| Motor Model Code | SC65E | Caster Angle | 27.0 Degrees |
|---|---|---|---|
| Bore (mm) | 73.5 | Trail (mm) | 114 |
| Storke (mm) | 67.2 | Minimum Ground Clearance | - |
| Compression Ratio | 9.5 | Distance Between Axes | - |
| Ignition Method | Full Transistor Battery Ignition | Streering Angle (Right) | - |
| Engine Lubrication Type | Force Feeding & Splash | Turning Angle (Left) | - |
| Frame Type | Double Cradle | Mirror Screw Hole Diameter | 10mm |
| Minimum Rotaion Radius | 2.7 | Fuel Tank Reserve Capacity | - |
[Underbody detail]
| Front Brake Type | Hydraulic Double Disc (ABS) | Suspension Type (Rear) | Swing Arm |
|---|---|---|---|
| Front Brake Remarks | - | Number of Rear Shock Absorbers | - |
| Rear Brake Type | Hydraulic Disc[ABS] | Rear Suspension Stroke | - |
| Rear Brake Remarks | - | Rear Wheel Travel | - |
| Suspension Type (Front) | Telescopic | ABS | Available |
| Front Fork Type | Upright Fork | Drive Train | Chain |
| Front Suspension Stroke | - | Differential Oil Amount | - |
| Front Fork Diameter | - | Chain Remarks | - |
[Equipment]
| Seat Lowering Allowance | - | Theft Prevention Device | Available |
|---|---|---|---|
| Mirror Screw Hole Diameter | 10mm | Tail Light Bulb Type | - |
| Mirror Remarks | Genuine Adapter: Type D | Tail Light Base Shape | - |
| Electronic Device Remarks | - | Tail Light Base Shape 2 | - |
| Fuel Gauge | Available | Tail Light Remarks | - |
| Clock | Available | Front Blinker Bulb Type | - |
| Hazard | - | Front Blinker Base Shape | - |
[Engine detail]
| Clutch Type | Wet-Type Multi-Plate Coil Spring Type | Tappet Clearance (mm) EX | - |
|---|---|---|---|
| Transmission | Permanently Engaged 5-Stage Return Shift | Idling Initial Value (rpm) | - |
| Number of Gears | 5 | Needle Steps (Clip Location) | - |
| Gear Ratio | 3.166 / 2.062 / 1.545 / 1.250 / 1.111 | Float Level (mm) | - |
| Primary Reduction Ratio | 1.652 | Air Screw Return | - |
| Secondary Reduction Ratio | 2.167 | Main Jet Type | - |
| Variable Speed Vehicle Gear Ratio | - | Main Jet Number | - |
| Tappet Clearance (mm) IN | - |
[Other spec]
| Clutch Cable Length | 910 | Rear Brake Cable Length | 560 |
|---|---|---|---|
| Choke Cable Length | 800 | Other Cables | Direct (R)770/(L)800 |
| Meter Cable Length | 940 | Engine Number (Production Launch) | - |
| Throttle Cable Length | 850/880 | Engine Number (Production End) | - |
| Front Brake Cable Length | Direct (R)770/(L)800 |
