Model Name:ESTRELLA
Manufacturer:KAWASAKI
Model Year:1992
KAWASAKI had sprinkled a lot of details on this model to make it resemble the famous premier bike, MEGURO. The air-cooled single engine which was intentionally loaded on its classical style body was new. The vibration was reduced by the work of a single axis balancer. It made the rider feel its power and hear its unique crispy sound.
Specifications:
[Basic spec]
| Manufacturer | KAWASAKI | Engine Type | Air-Cooled 4 Stroke Single Cylinder SOHC 2-Valve |
|---|---|---|---|
| Model Name | ESTRELLA | Starter | Self Starter |
| Grade | - | Maximum Output (ps) | 20ps(15kw)/7500rpm |
| Drive Train | - | Maximum Torque (kgf/m) | 2.1kg-m(20.6N-m)/6000rpm |
| Model Type | BJ250B/C(BJ250A) | Curb Weight | 153 |
| Displacement | 249 | Dry Weight | 151(Approximate Value) |
| Sales Launch Year | 1992/0 | Fuel Efficiency by Catalog | - |
| Height/Width/Length | 1035/-/2075 | Fuel Tank Capacity | 14 |
| Seat Height | - | Distance to Empty | - |
| Front Tire Indication | 90/90-18 51P | Fuel Supply | Injection |
| Rear Tire Indication | 110/90-17 60P |
[Service data]
| Standard Plug | DR8EA X27ESR-U | Chain Size | 520 |
|---|---|---|---|
| Number of Used Plugs | 1 | Chain Link Number | 102 |
| Engine Oil Amount | 2 | Battery Code | YTX9-BS 12V-8Ah |
| Engine Oil (Refill) | 1.8L | Headlight | 12V 60w/55w |
| Engine Oil (Element Replacement) | 2L | Headlight Type | H4 |
| Front Blinker Rating | 12V 15w | Headlight Remarks | - |
| Drive Sprocket Teeth Number | 15 | Tail Light Rating | 12V 21w/5w |
| Driven Sprocket Teeth Number | 38 | Rear Blinker Rating | 12V 15w |
[Machine detail]
| Motor Model Code | BJ250AE | Caster Angle | - |
|---|---|---|---|
| Bore (mm) | 66 | Trail (mm) | - |
| Storke (mm) | 73 | Minimum Ground Clearance | - |
| Compression Ratio | - | Distance Between Axes | - |
| Ignition Method | - | Streering Angle (Right) | 40 |
| Engine Lubrication Type | - | Turning Angle (Left) | 40 |
| Frame Type | Semi Double Cradle | Mirror Screw Hole Diameter | 10mm |
| Minimum Rotaion Radius | - | Fuel Tank Reserve Capacity | - |
[Underbody detail]
| Front Brake Type | Single Disc | Suspension Type (Rear) | Swing Arm |
|---|---|---|---|
| Front Brake Remarks | - | Number of Rear Shock Absorbers | 2 |
| Rear Brake Type | Disc | Rear Suspension Stroke | - |
| Rear Brake Remarks | - | Rear Wheel Travel | - |
| Suspension Type (Front) | Telescopic | ABS | - |
| Front Fork Type | Upright Fork | Drive Train | Chain |
| Front Suspension Stroke | - | Differential Oil Amount | - |
| Front Fork Diameter | - | Chain Remarks | - |
[Equipment]
| Seat Lowering Allowance | - | Theft Prevention Device | - |
|---|---|---|---|
| Mirror Screw Hole Diameter | 10mm | Tail Light Bulb Type | S25 |
| Mirror Remarks | - | Tail Light Base Shape | BAY15D |
| Electronic Device Remarks | - | Tail Light Base Shape 2 | - |
| Fuel Gauge | - | Tail Light Remarks | Glass Shape G18 Also Installable |
| Clock | - | Front Blinker Bulb Type | T13 |
| Hazard | - | Front Blinker Base Shape | Wedge (Medium)/Wedge (Medium) |
[Engine detail]
| Clutch Type | Wet Multiple Plate | Tappet Clearance (mm) EX | 0.17-0.22 |
|---|---|---|---|
| Transmission | - | Idling Initial Value (rpm) | 1100-1300(rpm) |
| Number of Gears | - | Needle Steps (Clip Location) | - |
| Gear Ratio | - | Float Level (mm) | 17 plus-minus 2 |
| Primary Reduction Ratio | - | Air Screw Return | 1.25 |
| Secondary Reduction Ratio | 2.53 | Main Jet Type | KEIHIN Round Large (E) |
| Variable Speed Vehicle Gear Ratio | - | Main Jet Number | #122 |
| Tappet Clearance (mm) IN | 0.12-0.17 |
[Other spec]
| Clutch Cable Length | 1170 | Rear Brake Cable Length | 360 |
|---|---|---|---|
| Choke Cable Length | - | Other Cables | Direct (R)770 |
| Meter Cable Length | 735 | Engine Number (Production Launch) | - |
| Throttle Cable Length | 975/1000 | Engine Number (Production End) | - |
| Front Brake Cable Length | Direct (R)770 |
