Model Name:TL1000R
Manufacturer:SUZUKI
Model Year:1998
It came with an aluminum twin spar frame, inverted front fork, and a rear suspension with a rotary damper. It was designed for race use.
Specifications:
[Basic spec]
| Manufacturer | SUZUKI | Engine Type | Water-Cooled 4 Cycle V-Shaped 2 Cylinder DOHC 4-Valve |
|---|---|---|---|
| Model Name | TL1000R | Starter | - |
| Grade | - | Maximum Output (ps) | 135ps(99kw)/9500rpm |
| Drive Train | - | Maximum Torque (kgf/m) | 10.5kg-m(103.0N-m)/7500rpm |
| Model Type | - | Curb Weight | 223 |
| Displacement | 995 | Dry Weight | 197 |
| Sales Launch Year | 1998/0 | Fuel Efficiency by Catalog | - |
| Height/Width/Length | 1125/-/2105 | Fuel Tank Capacity | - |
| Seat Height | - | Distance to Empty | - |
| Front Tire Indication | 120/70ZR17 58W TL | Fuel Supply | Injection |
| Rear Tire Indication | 190/50ZR17 73W TL |
[Service data]
| Standard Plug | CR8EK | Chain Size | 530 |
|---|---|---|---|
| Number of Used Plugs | 2 | Chain Link Number | 104 |
| Engine Oil Amount | - | Battery Code | FT12A-BS |
| Engine Oil (Refill) | 3.1L | Headlight | 12V 55w |
| Engine Oil (Element Replacement) | 3.3L | Headlight Type | H1 |
| Front Blinker Rating | 12V 21w/5w | Headlight Remarks | - |
| Drive Sprocket Teeth Number | 17 | Tail Light Rating | 12V 21w/5w |
| Driven Sprocket Teeth Number | 39 | Rear Blinker Rating | 12V 21w |
[Machine detail]
| Motor Model Code | T501 | Caster Angle | - |
|---|---|---|---|
| Bore (mm) | - | Trail (mm) | - |
| Storke (mm) | - | Minimum Ground Clearance | - |
| Compression Ratio | - | Distance Between Axes | - |
| Ignition Method | - | Streering Angle (Right) | - |
| Engine Lubrication Type | - | Turning Angle (Left) | - |
| Frame Type | - | Mirror Screw Hole Diameter | - |
| Minimum Rotaion Radius | - | Fuel Tank Reserve Capacity | - |
[Underbody detail]
| Front Brake Type | Double Disc | Suspension Type (Rear) | - |
|---|---|---|---|
| Front Brake Remarks | - | Number of Rear Shock Absorbers | - |
| Rear Brake Type | Disc | Rear Suspension Stroke | - |
| Rear Brake Remarks | - | Rear Wheel Travel | - |
| Suspension Type (Front) | - | ABS | - |
| Front Fork Type | - | Drive Train | - |
| Front Suspension Stroke | - | Differential Oil Amount | - |
| Front Fork Diameter | - | Chain Remarks | - |
[Equipment]
| Seat Lowering Allowance | - | Theft Prevention Device | - |
|---|---|---|---|
| Mirror Screw Hole Diameter | - | Tail Light Bulb Type | S25 |
| Mirror Remarks | Cowl Mirror | Tail Light Base Shape | BAY15D |
| Electronic Device Remarks | - | Tail Light Base Shape 2 | - |
| Fuel Gauge | - | Tail Light Remarks | Glass Shape G18 Also Installable |
| Clock | - | Front Blinker Bulb Type | S25 |
| Hazard | - | Front Blinker Base Shape | BAY15D/BA15S |
[Engine detail]
| Clutch Type | - | Tappet Clearance (mm) EX | - |
|---|---|---|---|
| Transmission | - | Idling Initial Value (rpm) | - |
| Number of Gears | - | Needle Steps (Clip Location) | - |
| Gear Ratio | - | Float Level (mm) | - |
| Primary Reduction Ratio | - | Air Screw Return | - |
| Secondary Reduction Ratio | 2.294 | Main Jet Type | - |
| Variable Speed Vehicle Gear Ratio | - | Main Jet Number | - |
| Tappet Clearance (mm) IN | - |
[Other spec]
| Clutch Cable Length | - | Rear Brake Cable Length | - |
|---|---|---|---|
| Choke Cable Length | - | Other Cables | - |
| Meter Cable Length | - | Engine Number (Production Launch) | - |
| Throttle Cable Length | - | Engine Number (Production End) | - |
| Front Brake Cable Length | - |
