Model Name:TEMPTER
Manufacturer:SUZUKI
Model Year:1997
It was brought to the market as the rival model of SR. It mounted a single engine based on the ones of SAVAGE. It was designed in a classic style by having a H-shaped aluminum rim and a front double panel drum brake.
Specifications:
[Basic spec]
| Manufacturer | SUZUKI | Engine Type | Air-Cooled 4 Stroke OHC 4-Valve Single Cylinder |
|---|---|---|---|
| Model Name | TEMPTER | Starter | Self Starter |
| Grade | - | Maximum Output (ps) | 27ps(19.9kw)/7000rpm |
| Drive Train | - | Maximum Torque (kgf/m) | 3.0kg-m(29.4N-m)/5000rpm |
| Model Type | - | Curb Weight | 173 |
| Displacement | 396 | Dry Weight | 159 |
| Sales Launch Year | 1997/4 | Fuel Efficiency by Catalog | 43.5 km/L (at 60 km/h) |
| Height/Width/Length | 1040/-/2110 | Fuel Tank Capacity | 12 |
| Seat Height | - | Distance to Empty | - |
| Front Tire Indication | 100/90-18 56S | Fuel Supply | Carburetor |
| Rear Tire Indication | 130/80-17 65S |
[Service data]
| Standard Plug | DPR8EA-9 | Chain Size | 520 |
|---|---|---|---|
| Number of Used Plugs | 1 | Chain Link Number | 110 |
| Engine Oil Amount | 2.4 | Battery Code | FTX9-BS |
| Engine Oil (Refill) | 1.8L | Headlight | 12V 60w/55w |
| Engine Oil (Element Replacement) | 2.4L | Headlight Type | H4 |
| Front Blinker Rating | 12V 18w/5w | Headlight Remarks | - |
| Drive Sprocket Teeth Number | 15 | Tail Light Rating | 12V 21w/5w |
| Driven Sprocket Teeth Number | 45 | Rear Blinker Rating | 12V 18w |
[Machine detail]
| Motor Model Code | K409 | Caster Angle | 26.8 Degrees |
|---|---|---|---|
| Bore (mm) | 88 | Trail (mm) | 110 |
| Storke (mm) | 65.2 | Minimum Ground Clearance | - |
| Compression Ratio | 8.5 | Distance Between Axes | - |
| Ignition Method | Full Transistor | Streering Angle (Right) | 35 |
| Engine Lubrication Type | Wet Sump | Turning Angle (Left) | 35 |
| Frame Type | Semi Double Cradle | Mirror Screw Hole Diameter | - |
| Minimum Rotaion Radius | 2.8 | Fuel Tank Reserve Capacity | - |
[Underbody detail]
| Front Brake Type | Twin Leading | Suspension Type (Rear) | - |
|---|---|---|---|
| Front Brake Remarks | - | Number of Rear Shock Absorbers | - |
| Rear Brake Type | Leading Trailing | Rear Suspension Stroke | - |
| Rear Brake Remarks | - | Rear Wheel Travel | - |
| Suspension Type (Front) | - | ABS | - |
| Front Fork Type | - | Drive Train | - |
| Front Suspension Stroke | - | Differential Oil Amount | - |
| Front Fork Diameter | - | Chain Remarks | - |
[Equipment]
| Seat Lowering Allowance | - | Theft Prevention Device | - |
|---|---|---|---|
| Mirror Screw Hole Diameter | - | Tail Light Bulb Type | S25 |
| Mirror Remarks | - | Tail Light Base Shape | BAY15D |
| Electronic Device Remarks | - | Tail Light Base Shape 2 | - |
| Fuel Gauge | - | Tail Light Remarks | Glass Shape G18 Also Installable |
| Clock | - | Front Blinker Bulb Type | S25 |
| Hazard | - | Front Blinker Base Shape | - |
[Engine detail]
| Clutch Type | Wet Multiple Plate Coil Spring | Tappet Clearance (mm) EX | - |
|---|---|---|---|
| Transmission | Permanently Engaged 5-Stage Normal Shift | Idling Initial Value (rpm) | - |
| Number of Gears | 5 | Needle Steps (Clip Location) | - |
| Gear Ratio | 2.333 / 1.578 / 1.142 / 0.956 / 0.833 | Float Level (mm) | - |
| Primary Reduction Ratio | 2.218 | Air Screw Return | - |
| Secondary Reduction Ratio | 3 | Main Jet Type | - |
| Variable Speed Vehicle Gear Ratio | - | Main Jet Number | #122.5 |
| Tappet Clearance (mm) IN | - |
[Other spec]
| Clutch Cable Length | - | Rear Brake Cable Length | - |
|---|---|---|---|
| Choke Cable Length | - | Other Cables | - |
| Meter Cable Length | - | Engine Number (Production Launch) | - |
| Throttle Cable Length | - | Engine Number (Production End) | - |
| Front Brake Cable Length | - |
